IRMA MATRIX
R2 CAN Installation manual
released
Rev. 1.6
2018-09
On typical bus doors being e.g. 2.05 m high and 1.30 m wide and with the sensor in the
optimum position in the center of the upper door trim, the entire (clear) passage area to be
monitored is covered by one sensor.
If it is not possible to install the sensors in the centre of the doors or of the doors are very
wide / low, the installation position and the number of sensors for each door must be
discussed and agreed in advance with iris-GmbH.
