Page #42 background image
42
/74
IRMA MATRIX
R2 CAN Installation manual
released
Rev. 1.6
2018-09
Table 12: Pin assignment of operating interface J1708
when using potential free door contact switches
Pin
Use
Wire color
1
2
Ground
3
Data, pos. pole
Yellow
4
Data, neg. pole
Green
5
Reference potential J1708
6
Reference potential J1708
7
8
Door 3, contact "b"
Brown
9
10
Door 3, contact "a"
White
11
12
Door 2, contact "b"
Violet
13
14
Door 2, contact "a"
Orange
15
16
Door 1, contact "b"
Blue
17
18
Door 1, contact "a"
Grey
