SBC950
118
1. INSPECTION OF HYDRAULIC HOSES
a When operating the collector, be sure to check that
hydraulic hose is not pulled and interfered.
b. When the hydraulic hose is damaged, change it as
soon as possible.
DANGER: It is dangerous to operate the
front mower with damaged hydraulic hose.
It may cause the collector to fall down or a
hydraulic line to burst suddenly.
2. GREASING POINTS
Grease up the points mentioned below periodically.
(As same as opposite side)
DANGER: When applying to grease point of
lift cylinder, make sure to lift the collector
and lock another side of the lift cylinder by
lift locks. It is dangerous to grease without
lift locks.
CHAPTER 3. INSPECTION AND MAINTAINANCE OF MAJOR PARTS
Inject until grease overflows
Quantity
1
2
3
4
Lift link
Dump link
Lift cylinder
Dump cylinder
Lubricants
Grease
Filling points
Ref. No.
To Next Page
