Iseki SBC950 - Loading Onto or Unloading from Atruck

CHAPTER 1. FOR SAFE OPERATION
13
6. LOADING ONTO OR UNLOADING FROM A
TRUCK
6.1. When loading the front mower onto a truck, turn
off the truck's engine, apply the parking brakes
to the truck, and chock the wheels to avoid
unexpected moving of the truck or trailer.
6.2. Pay sufficient attention to safety conditions
around the front mower and have it guided by
someone to assist the operator. Never allow other
persons to approach the front mower, especially
in front of or behind it.
6.3. When loading the front mower onto a truck, lift up
the mower deck fully and advance it straight at
sufficiently low speeds. Drive it backward when
unloading it from the truck or trailer.
6.4. If the engine stalls unexpectedly on the ramps,
depress the brake pedals immediately and roll the
front mower to the ground by releasing the brakes
gradually. Then start the engine and try again.
6.5. Use ramps with the same or better specifications
mentioned below. When the front mower is
equipped with attachments other than those
included in the specifications mentioned below,
ask your dealer for advice.
Specifications of the ramps
・Length........... more than 4 times the height of the
platform of the truck
・Width (effective width) ..............more than 30 cm
・Required quantity ...................................2 ramps
・Capacity (one ramp) ...............more than 750 kg
・Ramps should have anti-skid surfaces.

・
The above specifications are effective with the
front mower with the following configurations.
- The front mower is not equipped with any
attachments or a cabin than a standard mower
deck and collector.
- The front mower is equipped with a standard
mower deck and collector.
6.6. Park the truck on hard level ground. Hook the
ramps securely on the platform of the truck with
the top of the ramp level with the platform.
6.7. Drive the front mower carefully at the moment
when the front mower moves from the ramps onto
the platform for it changes angles abruptly.
6.8. When the front mower is loaded on the truck,
lower the mower deck onto the truck bed, stop
the engine, apply parking brakes, and withdraw
the starter key, chock the wheels, and rope it
securely to the truck. Refrain from unnecessary
abrupt starting, stopping, and turning during
transportation, or the front mower may shift
position on the truck, which is very dangerous.
FIG. 12
FIG. 13
