SF224,235
48
3. TRAVELLING
CAUTION:
・
Before having become sufficiently familiar
with the operation of the front mower, be
sure to operate it in a spacious, flat and
unobstructed place with good visibility,
and confirm the function of each control.
・
Check the place to mow beforehand for
bumps, ditches, mounds, steps, slopes,
inclination, softness, water pools and
etc. in order to avoid accidents such as
turnover, fall, side-sliding of the front
mower.
a. Start the engine. (Refer to Chapter 7.2)
b. Depress the brake pedal,1, fully.
CAUTION:
・
Before having become sufficiently familiar
with the operation of the front mower,
operate it at the LOW speed position.
・
When travelling on bumps, ditches,
mounds, steps, inclination softness,
waterhole, etc, select the throttle lever at
the LOW speed position.
c. (When mowing) : Move the throttle lever, 2, to the
HIGH speed position to accelerate the engine.
(When travelling) : Move the throttle lever to the
HIGH speed position.
d. Shift the mower lift lever, 3, to UP position to lift up
the mower deck from the ground.
e. When front mower is attaching a collector, be sure
to lower the container.
CAUTION: Starting to travel at high speeds
without lifting up the mower deck will cause
the mower blades to hit stones or stocks,
which may result in break-down of the front
mower or serious accidents.
CAUTION When starting to travel, be sure to
lower the container. Otherwise it may cause
the front mower to turn over, which is very
dangerous.
(2) Throttle lever A: High speed B: Low speed
(3) Mower lift lever
FIG. 45
FIG. 46
3
A B
2
(1) Brake pedal
(4) Parking brake lever
(5) HST forward travel pedal
(6) HST reverse travel pedal
