Iseki SBC950 - Filling Diagram

CHAPTER 8. MAINTENANCE
71
26. FILLING DIAGRAM
Ref.No Filling points Lubricants Quantity: liter
1 Radiator LLC50% 2.5
2 Reserve tank LLC50% 1.0
3 Engine Engine Oil 2.4-3.5(SF224), 3.0-4.8(SF235).
4 Rear axle Gear oil #80 3.7
5 Transmission case Shell donax TD 16.0
6 Knuckle spindles Grease As required
7 HST pedal hub Grease As required
8 Brake shaft Grease As required
9 Fuel tank Diesel fuel 40.0
10 Brake Pedal Grease As requried
11 Diff lock pedal Grease As requried
12 Chain case Gear oil #80 1.6
13 4WD case Gear oil #80 0.2
