CHAPTER 4. NAME OF MAJOR COMPONENTS
35
CHAPTER 4. NAME OF MAJOR COMPONENTS
FIG. 27
(1) Mower lift lever
(2) Diff-lock pedal
(3) Parking brake lever
(4) Throttle lever
(5) Collector dump lever
(6) Collector lift lever
(7) Tilt lever
(8) Control panel
(9) Brake pedal
(10) HST forward travel pedal
(11) HST reverse travel pedal
(12) 4WD lever
(13) Cup holder
