SF224,235
32
MOWER DECKS
Model SCMA 54 SCMB60 SSM54
Type Rotary mower
Cutting width 1372 mm (54 in.) 1524 mm (60 in.) 1372 mm (54in.)
No. of blades 2 2 x 2 3
Dimensions
Overall length 1010 mm (39.8 in.) 1288 mm (50.7 in.) 955 mm (37.6 in.)
Overall width 1440 mm (56.7 in.) 1571 mm (61.8 in.) 1710 mm (67.3 in.)
Overall height 445 mm (17.5 in.) 419 mm (16.5 in.) 450 mm (17.7 in.)
Weight
Deck 103 kg (227.1 lb) 203 kg (447.5 lb) 130 kg (286.6 lb)
Linkage 20 kg (44.1 lb) -
Chuter 2 kg (4.4 lb) -
Cutting-height adjustment1
Adjustable in 2 stages
by pin replacement
Adjustable in 2 stages
by pin replacement
Adjustable in 6 stages
by pin replacement
Cutting-height adjustment2
Adjustable in 10 stages
by pin replacement
Adjustable in 10 stages
by pin replacement
None
Cutting heights
25-120 mm (1.0-4.7 in.) 25-120 mm (1.0-4.7 in.) 30-120 mm (1.2-4.7 in.)
COLLECTOR
Model SBC950
Type -
Dimensions
Overall length 1400 mm (55.1 in.)
Overall width 1100 mm (43.3 in.)
Overall height 1750 mm (68.9 in.)
Weight 160 kg (352.7 lb.)
Container capacity 950 liters
Height of lift 2125mm (83.7 in.)
Height of dump 1935mm (76.2 in.)
Lift system Hydraulic
Dump system Hydraulic
No. of lift cylinder 2
No. of dump cylinder 2
Piston & cylinder
Dia. x stroke
Lift 25 x 45 x 261 mm
Dump 20 x 40 x 206 mm
Full sensor system -
