Chapter 5 Troubleshooting
ID NO.
TITLE ERROR CONTENTS SOLUTION
0405 FIFO FOR
WRAPPER IS FULL
FIFO for wrapper is full.
The wrapper software is managing
the wrapping movement by putting
the sequence numbers on each
product. But, at this time, the
declination of management of
sequence number occurred, and the
machine could not continue
wrapping movement.
It is not the main software but the
wrapper software that cause FIFO
over.
REBOOT
0406 WRAPPER
DETECTED
TEMPORARY
BLACKOUT
Temporary blackout occurred at the
wrapper side.
CPU at the wrapper control unit was
reset.
REBOOT
The wrapper software received other
commands than power is ON
command when the machine got
powered ON.
0407 TEMPORARY
BLACKOUT ON
CONSOLE
Temporary blackout occurred at the
console (=printer side).
CPU at the console (=printer side)
was reset.
REBOOT
0410 LIFT MOTOR IS
ABNORMAL
Lift motor error
Lift motor did not move properly.
<SUB ERROR No.>
0001: The movement protection
timer ended, but actual
movement is not completed.
0002: Cannot detect the speed
pulse signal from DCB
driver board.
0999: The speed pulse from the
DCB Driver became lower
than 600rpm.
(It appears when the package is
jammed between rear folder and the
discharge unit, or when the
emergency stop button is pressed
during operation.)
[RETURN]
<Check Point>
1. DCB driver [E1]
2. DCB motor [M1]
3. Lift home position sensor [B1]
4. Check the wiring of the electro
magnetic unit [K1] (1L1, 2T1, 3L2,
4T2)
5. Cable between XJ17 of P-1004 and
DCB driver (E1-CN2)
6. Cable between XJ11 of P-1004 and
lift home position sensor
7. Cable between electro magnetic
unit and DCB driver
5-15
