Chapter 5 Troubleshooting
ID NO.
TITLE ERROR CONTENTS SOLUTION
0415 REAR FOLDER IS
NOT ORIGINAL
POSITION
Rear folder is not at the original
position. (SUB ERROR No.:0010)
When the rear folder starts moving,
the rear folder home position sensor
did not detect the rear folder.
<SUB ERROR No.>
0010: Without the Rear folder home
position sensor (no
connection between P-1004
XJ13 18 pin and 20 pin), as
the confirmation function of
rear folder home position
becomes ineffective, this error
does not appear.
0012: When the rear folder starts
moving, the rear folder home
position sensor detected the
rear folder.
Without the Rear folder
home position sensor (no
connection between P-1004
XJ13 25 pin and 26 pin), as
the confirmation function of
rear folder home position
becomes ineffective, this
error does not appear.
[RETURN]
<Check Point>
1. Check the rear folder operation
completion verification sensor
[B16].
2. Check XJ10 of P-1004 [A1].
5-16
To Next Page
