ISHIDA WM-NANO Service Manual

Appendix 2 Wrapping by WM-NANO
Appendix 2-5
<M type>
Ishida Wrap/Ishida Wrap Super: Film width 400mm
Trays with good wrapping condition Trays impossible for wrapping
●：Verified for wrapping feasibility by tests
Long side of the tray[mm]
Short side of the tray
150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330
210
200
190
180
●
170
● ●
160
●
150
● ●
140
● ● ●
130
●
120
● ● ● ●
110
●
100
90
Figure 8
<M type>
Ishida Wrap/Ishida Wrap Super: Film width 450mm
Trays with good wrapping condition Trays impossible for wrapping
●：Verified for wrapping feasibility by tests
Long side of the tray[mm]
Short side of the tray
150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330
210
●
200
● ●
190
180
●
170
● ●
160
●
150
● ●
140
● ● ●
130
120
110
100
90
Figure 9
