Chapter 3 Adjustment Mode
6） Remove screws (3) to remove the back-left cover.
7） Remove screws (2) to remove the back-right cover.
8） Loosen the screws (2) on the left side of the
discharge unit’s cover.
9） Loosen the screws (2) on the right side of the
discharge unit’s cover.
Loosen the screws on the
left lateral.
Back left cover
Back right cover
3-10
