www.janitza.com UMG 804
13
5. Technical data
General
Device dimensions (approx.) w=158.7 mm, h=108.5 mm, d=59.2 mm
(w=6.248 in, h=4.271 in, d=2.330 in)
Transport and storage
The following information applies to devices which are transported or stored in the original packaging.
Temperature -40 °C to 70 °C (-40 °F to 158° F)
Ambient conditions during operation
The device is intended for weatherproof, fixed installation and must be connected to the ground wire
connection! Protection class I in acc. with IEC 60536 (VDE 0106, Part 1).
Working temperature range 0 °C to 60 °C (32 °F to 140 °F)
Relative humidity < 95 % RH (without condensation)
Operating altitude 0 .. 2000 m (1.24 mi ) max.
Pollution degree pollution degree 2
Mounting position any orientation
Ventilation not required; 3 W heat rejection
Protection against ingress of solid foreign
bodies and water
requires secondary enclosure
AC Power Supply
Installations of overvoltage category internally fused; install external fuse as required by code
Protection of the supply voltage (fuse) 1 A @ 300 V AC
Overvoltage category II, degree 2
Operating range 90 .. 300 V AC (50-60 Hz)
Power consumption <0.1 A @ 277 VAC (< 3 W)
Terminal connection capacity (AC supply voltage)
Connectable conductors. Only one conductor can be connected per terminal!
Single core, multi-core, fine-stranded 24-12 AWG / 0.205-3.31 mm²
Terminal pins, core end sheath slot screw type
Tightening torque 5.0 Lb-In / 0.56 Nm
Stripping length 5.5 mm (0.22 in) max.
24 V DC Power Supply
Installations of overvoltage category internally fused; install external fuse as
required by code
Protection of the supply voltage (fuse) 0.5 A @ 24 V DC
Overvoltage category III, degree 2
Operating range 12 .. 24 V DC
Power consumption < 0.5 A @ 12 .. 24 V (< 3 W)
Terminal connection capacity (DC supply voltage)
Rigid/flexible 22-16 AWG / 0.324-1.31 mm²
Flexible with core end sheath without
plastic sleeve
22-16 AWG / 0.324-1.31 mm²
Flexible with core end sheath with
plastic sleeve
22-16 AWG / 0.324-1.31 mm²
Tightening torque 5.0 Lb-In / 0.56 Nm
Stripping length 5 mm (0.20 in) recommeded
