UMG 804 www.janitza.com
52
1
IP Address: Default is always 192.168.5.77
2
NetMask
3
Gateway IP
4
Primary DNS IP
5
NTP server: NTP server is utilized for date and time references. Consult your system adminis-
trator for details or leave as default and time will be synced to time.google.com
6
BACnet UDP Port: Only required for BACnet applications.
7
BACnet Device ID: Only required for BACnet applications.
14.2 Network
14.2.1 Ethernet Settings
Ethernet
Serial
For any of the changes to be
captured, the user must click
on „Update Settings“, and then
confirm with „Apply Changes“.
2
1
3
4
5
6
7
· The Ethernet Settings tabs allows for all IP based
settings to be configured. These settings may
also be configured using the config.csv file via
USB drive or direct input from a Modbus write
command.
· The factory default IP is always 192.168.5.77
· The PC or device must be set to the same subnet
as the IP address on the UMG 804 (see modify-
ing subnet (i.e 192.168.5.XXX) on PC for more
details).
· Lost IP address: The IP address can also be
revealed by inserting an USB into the UMG 804
and removing after approximately 20 seconds
and a IPSetting.txt file will be written on the USB
drive with the IP address.
· Note that if not using BACnet select disable
BACnet.
