14.4.5 True Meter
· True Meter Mapping allows individual circuits/
channels to be grouped as one, two or three
phase meters and read as a single meter meter
with total readings for the meter.
· For example: if channels 1, 2, 3 are a three-phase
circuit, you can now obtain readings for a single
three-phase circuit rather than having to sum
three independent channels.
· True Meter Mapping will mathematically derive
the neutral current on three phase circuits, elimi-
nating the need for a CT.
INFORMATION
Important : Always remember to select the
Save Settings button to save changes to
settings.
