janitza UMG 804 User Manual

UMG 804 www.janitza.com
22
1 2 3 4
CT
STRIP 1
CT
STRIP 2
CT
STRIP 3
CT
STRIP 4
PORT 1 PORT 2 PORT 3 PORT 4
ModBus Address “X”
Panel 1 Panel 2
ModBus Address “X”+1
Fig.: Cable Ports
For circuit destination refer to „8.3 Panel Maps
Confi guration“ on page 30 or „9.3 Panel Maps
Confi guration“ on page 41, respectively.
