computer radio control system
EN
Pairing the transmitter with receivers in Double Path mode
1. Make sure that receivers are set in Normal mode, not in Clone
mode.
2. Note down which receiver is the first and which is the second
because of later easier identification. Keep the receivers switched
off.
3. Switch on the transmitter with created model, in „Advanced
properties - Wireless modes/Trainer” menu item select „Double
Path mode”.
4. Plug the BIND PLUG interconnection into EXT output of the first
receiver. Switch on the receiver. Now the receiver expects a
sequence for pairing (in case you have Rx firmware version 3.11 and
newer, this period is limited up to 60s).
5. Press „3D pushbutton” on the transmitter over "Pair primary TX
module" command. As soon as the receiver is identified, you will be
asked for confirmation – now push OK button. Switch off the receiver
and remove pairing interconnection.
6. Plug the BIND PLUG interconnection into EXT output of the
second receiver. Switch on the receiver.
7. Press „3D pushbutton” on the transmitter over "Pair secondary
TX module" command. As soon as the receiver is identified, you will
be asked for confirmation – now push OK button. Switch off the
receiver and remove pairing interconnection.
8. Switch on both receivers. The connection should be established
immediately, eventually servo control is allowed.
9. Now you can specify additional parameters of the Double Path
mode so that the transmitter correctly responds to the signal loss
from any of the receivers.
4. 4.
106
