computer radio control system
EN
8.3.2 Alternative pairing procedure through the
transmitter menu
1. Turn off the receiver. Keep the transmitter turned on.
2. Plug the "BIND PLUG" into the EXT receiver input.
3. Connect receiver power supply.
4. Locate the transmitter menu „Advanced Properties -> Wireless
Modes/Trainer”
5. Highlight "Pair primary TX module" and press the „3D button”.
6. The receiver will bind with the transmitter. Confirm the registered
device.
8.4 Range Test
The range test will verify that the transmitter and receiver are
functioning properly.
Before the first flight of each flying session or if have any doubts
about the transmitter or receiver function, you should always check
the range. During the range test the transmitter’s output power is
decreased to 10%.
When performing a range test, both the model and the transmitter
should be at a minimum height of 80 cm (31.5“) above the ground. A
correctly functioning transmitter and receiver in range test mode
should safely control a model to a minimum distance of 50m (164‘).
If not, check your model’s antenna installation first. If the test is still
not successful, don´t fly the equipment and contact your retail shop
or one of the JETI authorized service centers.
8.5 Fail safe
All Duplex 2.4GHz system receivers are equipped with „fail safe“, a
function which reacts to control signal transmission interruptions.
When your receiver for any reason does not receive transmitter
information, it changes, after a pre-set time period, to one of the
following modes.
„Repeat“ – This mode holds the last valid control throw signal ( this is
the default mode for all receivers)
„Out off“ – There is no output signal provided by the receiver, i. e.
servos do not keep their positions
„Failsafe“ – receiver outputs change to preset positions
3.3.
56
