computer radio control system
EN
4. 4.
between recording of proportional or two-state values (0% – 100%).
The control positions are recorded with a fixed period of 0.2s. The
data is a part of the standard telemetry record and can be displayed
as the other parameters.
This application can easily be used as a marker to highlight
interesting situations during the flight.
Conversion of Units
1. The voice synthesized telemetry units can be expressed in either
metric or US units. It is also possible to display the telemetry units on
the main screen in either format as well. The temperature is
automatically converted according to the option selected in the
Configuration menu. Conversion of the other units is accessible
through the Sensors/Logging menu. You can choose from the
following units:
Distance:
Metres (m), kilometres (km), feet (ft.), yards (yd.), miles (mi.).
Speed:
Metres per second (m/s), kilometres per hour (km/h), feet per second
(ft/s), miles per hour (mph) and knots (kt.).
Deleting a sensor
Above the „F3” function button the transmitter shows the number
of detected telemetry parameters from sensors and it is possible to
reset any unnecessary entry using the „F4” button. However, if the
button whose parameter has been deleted is still connected, the
parameter will later be re-loaded. The transmitters can detect up to
32 telemetry items.
9.4.6 Displayed Telemetry
This menu lists all of the user information blocks which are displayed
on the desktop. You can use this menu to manually add, delete,
rename and resize the user information blocks displayed on the
desktop.
User Block Overview:
"Flight mode" - Name of the current flight mode
„Voltage Rx“ - Receiver Voltage
121
