SECTION 3 - CHASSIS & TURNTABLE
3121714 3-33
MAE36590
CG
CL
3.9" (99.06 mm)
Figure 3-25. Swing Bearing Removal - E450A
Gross Weight (includes all components
except Chassis): 8256 lbs (3745 Kg)
Note: CG location may vary slightly depending
on the exact configuration of the machine.
