SECTION 3 - CHASSIS & TURNTABLE
3-34 3121714
MAE36600
CG
8.5" (216 mm)
CL
Figure 3-26. Swing Bearing Removal - E450AJ, M450AJ
Gross Weight (includes all components
except Chassis): 8426 lbs (3822 Kg)
Note: CG location may vary slightly depending
on the exact configuration of the machine.
