Pressing the Special Function key will reset the YZ part of the reading to 00, the X part will not be reset.
Characteristic values of the status register (YZ part)
-00 after switching power on (main shaft not moved at all), or after pressing the Special function key
-07 after 2 turns backward à A- and B channel signals are OK, but there is no synchronisation in backward
direction
-0b after 2 turns forward à A and B channel signals are OK, but there is no synchronisation in forward direction
-1b after 2 turns forward backward à A and B channel signals are OK, synchronisation in forward rotation is OK as
well.
-1F after 2 turns in each direction à A and B channel signals are OK, but synchronisation was made in forward
direction only
-27 after 2 turns backward à A and B channel signals are OK, synchronisation in backward direction is OK as well
-2F after 2 turns in each direction à A and B channel signals are OK, but synchronisation was made in backward
direction only
23F Incremental encoder was rotated by more than 2 turns in each direction and performs properly.
>-40 Synchronisation error in forward direction
>-80 Synchronisation error in backward direction.
Comments: If this test fails (no 23F) please check
• the cabling of the optoencoder – micro-controller
• the connectors of the cable
• clean the incremental encoder sleeve
C75 Display values from AD converter
Options: Choosing the AD channel
Special function: None.
Description:
AD input Channel Description
AdC 0 0.0 Free
AdC 1 1.0 fLED-CW LED current control
AdC 2 2.0 Free
AdC 3 3.0 fBAL-TMP Temperature of transducer (analog version if present)
AdC 4 4.0 Free
AdC 5 5.0 Free
AdC 6 6.0 Free
AdC 7 7.0 fBAT Supply voltage control (handspin)
AdC 8 8.0 fPOt-WHO Width potentiometer
AdC 9 9.0 fPOT-OFS Distance/extraction potentiometer
AdC 10 10.0 fPOT-DIA Diameter/angle potentiometer
AdC 11 11.0 Free
AdC 12 12.0 VCC-W ½ voltage of +5V supply
AdC 13 13.0 fLINE-V Mains voltage control
AdC 14 14.0 Free
AdC 15 15.0 Free
AdC 16 5.0 VDisp Supply voltage of display board (=VCC-W)
AdC 17 6.0 Free
AdC 18 5.1 Free
AdC 19 6.1 Free
AdC 20 5.2 VDisp* Supply voltage of display board (=VCC-W)
AdC 21 6.2 VAssStat* Voltage on capacitor of AutoStopSystem
AdC 22 5.3 Free
AdC 23 6.3
AdE 1 AE1 External AD converter (rear transducer)
AdE 2 AE2 External AD converter (front transducer)
* via multiplexer on the power interface
Free: 0.0V will be displayed
Comments: Voltage Range is: 0.0 - 3.3V for ELECTRONIC BOX
