iSTAR Edge G2 Controller Installation and Configuration Guide 39
Chapter 5 - Controls and Displays
Onboard Controls
iSTAR Edge G2 provides a number of a onboard controls.
Reset Button
The reset button performs a hard reset of the processor and erases the RAM memory. Flash memory, including backups and
ICU configuration information, is not erased by pressing the reset button.
NOTE
Use Rotary switch position D to clear flash memory and restore factory defaults.
Switches and Jumpers
Table 15describes the switches and jumpers on the iSTAR Edge G2 panel.
Table 15:Switches and Jumper Descriptions
Reference Type Description
SW1 Rotary Diagnostics, restore factory default & other options
S1 Pushbutton Reset
S12 Pushbutton SW Restart
S2 DIP slide RM port 1 termination
S3
DIP slide RM port 2 termination
S4 DIP slide RM port 3&4 termination
S8 DIP slide Board ID
JH29 4-pin header Relay #1 Wet12,Dry,Wet24 configuration
JH31 4-pin header Relay #1 Wet12,Dry,Wet24 configuration
JH33 4-pin header Relay #1 Wet12,Dry,Wet24 configuration
JH35 4-pin header Relay #1 Wet12,Dry,Wet24 configuration
Rotary Switch
There is an onboard 16 position rotary switch, SW1. Most of the positions are used to control LCD diagnostics. Table 16 on
Page 39 details the functions of each switch position.
Table 16:Rotary Switch Functions
Position Description
