iSTAR Edge G2 Controller Installation and Configuration Guide 83
Appendix 9 - Appendix
General Wiring Requirements
Table 26 displays the general wiring requirements for the iSTAR Edge G2 and its components.
Table 26:Equipment Wiring
Signal From To AWG Shield Max Length
RS-485 Comm,
two wire
iSTAR Edge
G2
RM and I/O Modules 22 Yes 4000 ft (1212m)
Power iSTAR Edge
G2
RM and I/O Modules 22/18 No Range of 600 ft to 1500 ft, depending on
AWG used.
RJ-45-Ethernet iSTAR Edge
G2
Hub, Host Cat 5e
24
N/A 328 ft (100m)
Supervised Input iSTAR Edge
G2
Input 22/18 No 2000 ft (606m)
Request-to-exit (REX or
RTE)
iSTAR Edge
G2
Switch 22/18 No 2000 ft (606m)
Door Contact (DSM) iSTAR Edge
G2
Contact 22/18 No 2000 ft (606m)
Supervised Input iSTAR Edge
G2
Input 22 Yes 2000 ft (606m)
Reader Input iSTAR Edge
G2
Proximity/Wiegand signaling
read head
22
20
18
Yes 200 ft (60.96m)
300 ft (91.4m)
500 ft (152.4m)
There are 2 jumpers on the PoE module:
• x1 jumper to select PoE or PoE Plus (+). Ensure the jumpers are set correctly if using PoE.
• x1 jumper to configure the voltage used to power the Edge G2 and to supply the wet relays for door locks. Set the
jumper to 24 VDC for the Edge G2.
— Do not connect the PoE injector to a receptacle controlled by a switch.
— The Tamper, Battery Low, and AC Power Fail inputs must be enabled and connected to report to comply with UL
requirements.
NOTE
Shielded cable must be used for AC Fail in Low Battery input connections.
Supervised Inputs must use shielded, 22 AWG (minimum) stranded, twisted-pair cable, such as Belden 9462 or equivalent, for monitor
points, DSMs, and REXs. Connections between PSE or power injector and the PD must use 26 AWG (0.13mm2) for patch cords and 24
AWG (0.21mm2) for horizontal or riser cables connected through standard 8-pin RJ-45 connectors.
