iSTAR Edge G2 Controller Installation and Configuration Guide 85
Appendix 9 - Appendix
Port Voltage Compatibility
Table displays the compatibility ranges of various reader ports with the iSTAR Edge G2 operating on 12 VDC, 24 VDC, or PoE
input power.
Table 28:Port Voltage Compatibility
12 VDC Input Power
Component/Board Compatibility Range
Wiegand Circuit 9.38 - 12 VDC
RM/RS485 Circuit 9.56 - 12 VDC
Relay (Wet, 12 VDC jumper setting) Circuit 8.99 - 12 VDC
Aux Output Circuit 9.71 - 12 VDC
NOTE: Reader ports are classified by UL as special application circuits when running on 12V DC in.
24 VDC Input Power
Component/Board Compatibility Range
Wiegand Circuit 12 VDC
RM/RS485 Circuit 12 VDC
Relay (Wet, 12 VDC jumper setting) 12 VDC
Relay (Wet, 24 VDC jumper setting) 21.79 - 24 VDC
Aux Output Circuit 12 VDC
NOTE: Reader ports are classified by UL as special application circuits when running on 24V DC in.
PoE Input Power
Component/Board Compatibility Range
Wiegand Circuit 12 VDC
RM/RS485 Circuit 12 VDC
Relay (Wet, 12 VDC jumper setting) 12 VDC
Relay (Wet, 24 VDC jumper setting) 24 VDC
Aux Output Circuit 12 VDC
