iSTAR Edge G2 Controller Installation and Configuration Guide 84
Appendix 9 - Appendix
Power Requirement for Readers
Table 27 shows the various power requirements for Software House readers compatible with the iSTAR Edge G2.
Table 27:Software House Reader Power Requirements
Reader Model Numbers Current Draw at 12 VDC
RM with Multi-Technology Reader RM1-4000, RM2-4000 300 mA max
RM with Multi-Technology Reader and LCD RM2L-4000 300 mA max
RM with mag stripe RM1-MP, RM2-MP 80 mA max
RM with mag stripe and LCD RM2L-MP 180 mA max
RM with mag stripe mullion RM3-MP 80 mA max
RM with Indala proximity RM1-P, RM2-PI 80 mA max
RM with Indala proximity and LCD RM2L-PI 180 mA max
RM with HID proximity RM1-PH, RM2-PH 250 mA max
RM with HID proximity and LCD RM2L-PH 250 mA max
RM with HID proximity mullion RM3-PH 250 mA max
RM with Wiegand RM1-W 80 mA max
Multi-Technology Contactless Reader SWH-4000, SWH-4100 SWH-4200, SWH-3000, SWH-3100 125 mA
Multi-Format Proximity Reader SWH-5000, SWH-5100 125 mA
Contactless Smart Card Reader SWH-2100 125 mA
Auxiliary Relay Module ARM-1 20 mA (relay active)
RM with HID iClass RM1-IC, RM2-IC 300 mA max
RM with HID iClass and LCD RM2L-IC 300 mA max
TST-100 Reader SWH-TST-100 180mA
HID RP40 920P and 920L 85mA
HID RPK40 921P and 921L 95mA
SWH 6000 Series SWH-6000 200mA max
