iSTAR Edge G2 Overview
The iSTAR Edge G2 is a cost-effective, 4-door controller that can be powered using Power-over-Ethernet (PoE) and is suitable
for installation above or near controlled doors. The iSTAR Edge G2 can be clustered with other iSTAR Edge G2 controllers.
C•CURE 9000 version 2.80 SP2 or newer is required for the iSTAR Edge G2.
Main Features and Specifications
The iSTAR Edge G2 includes the following features and associated specifications.
Processor
• iMX7 Processor.
Storage
• 2 GB of RAM.
• 16 GB of onboard flash memory.
NOTE
Refer to the card storage capacity calculator on www.swhouse.com for precise card storage capacity.
Power
The iSTAR Edge G2 is powered by a UL 603 or UL 2610 External Power Supply, such as the Software House apS or a Power
over Ethernet (PoE) injector with a UL listed surge protector, evaluated to UL 1449. The iSTAR Edge G2 can automatically
determine whether it is running on 12 VDC or 24 VDC power.
• Provides power to relays:
— The PoE+ module must be configured to supply 24VDC. Relays can still be configured for 12VDC or
24VDC.Relays are configurable as wet or dry by jumper.
— Wet relays provide current at main input voltage.
— Wet relays are limited to 0.75A (at 12 or 24VDC).
— Dry relays are limited to 3.0A (at 12 or 24VDC).
• If external power is lost, data is written to the onboard flash memory and the system is shut down.
NOTE
Full backup operating power is not supplied by the board. Use apS, external UPS, or back up the Power Sourcing Equipment in your PoE
system to ensure backup power can be supplied.
12
