iSTAR Edge G2 Controller Installation and Configuration Guide 13
Chapter 1 - Overview
Table 1:iSTAR Edge G2 Power Ratings
Product Circuit Voltage Current
Edge G2 Series
Input
DC input 12 or 24 VDC 5A
PoE Input -- Tested by UL with Phihong
POE125U-4-HP-R and POE36U-
1AT-R
Output
Wiegand (2 provided) 12 VDC 750mA each
RM/RS485 (4 provided) 12 VDC 1.2A each
Relay (configured for wet) 12 or 24 VDC per input voltage 750mA each
Relay (configured for dry) 30 VDC 3A inductive
Aux Power (2 provided) 12 VDC 350mA combined
NOTE
• When powered by 12/24VDC, total output is limited to 4.5A combined.
• When powered by the supported Phihong PoEs, total output is limited to 2A combined.
• To source 24VDC the Edge G2 must be powered by 24VDC.
Readers
• x2 Wiegand connectors are included.
• x2 RMs can be configured to provide 4 Wiegand connectors.
• x4 RM serial ports are included on 2 modules (Port 1 and 2 support full duplex mode).
• Readers can be any combination of 2 Wiegand ports and/or RMs on any of the 4 serial ports (the same type of reader
must be used on the same port).
Table 2 on Page 13 shows the maximum ratings for iSTAR Edge G2 Wiegand direct reader ports.
Table 2:iSTAR Edge G2 Wiegand Port Rating
Port Rating
Reader output control
(red, green, yellow, beeper)
Low = 0V to 0.8V
High = 4.0V to 5.25V
20 mA maximum
Reader input data lines Low = 0V to 0.8V
High = 4.0V to 5.25V
Reader output voltage +12 VDC
Reader current Wiegand reader current is 750mA per port. AUX power is 350mA total for the two connectors provided.
