iSTAR Edge G2 Controller Installation and Configuration Guide 48
Chapter 6 - Connections
Table 18:Supervision Mode
Mode Comment
NO/NC Dual EOL 1K Wire with Parallel/Serial for NO and Serial/Parallel for NC.
• Normal = 1K
• NO Alert = 0.5K
• NC Alert = 2K
NOTE: This the default value, and the traditional Software House method of supervision.
NO/NC Dual EOL 5K Wire with Parallel/Serial for NO and Serial/Parallel for NC.
• Normal = 5K
• NO Alert = 2.5K
• NC Alert = 10K
NO/NC Dual EOL 10K Wire with Parallel/Serial for NO and Serial/Parallel for NC.
• Normal = 10K
• NO Alert = 5K
• Alert = 20K
NC Single EOL 5K Series Resistor
• Normal = 5K
Alert = open (∞ Ω)
NO Single EOL 5K Parallel Resistor
• Normal = 5K
Alert = short (0 Ω)
NC Single EOL 10K Series Resistor
• Normal = 10K
Alert = open (∞ Ω)
NO Single EOL 10K Parallel Resistor
• Normal = 10K
Alert = short (0 Ω)
NC Non-Supervised No Resistors
• Normal = short (0 Ω)
Alert = open (0 Ω)
NO Non-Supervised No Resistors
• Normal = open (∞ Ω¦)
Alert = short (0 Ω)
NC Double EOL 1K Serial and Parallel Resistors
• Normal = 1K
Alert = 2K
