3.5.16 Marking [MARK]
A maximum of 20 marks can be indicated at arbitrary positions on the radar display.
A mark created on the radar display holds the latitude and longitude.
[I] Creating Marks
Procedure 1 Press [MARK] key.
[Ú§] will appear in the CURSOR field at the upper right of the radar display.
2 Put the cross cursor mark + on the position where a mark is to be
created, and press [ENT] key.
The cross cursor mark + will be changed into the [Ú§
] mark and fixed on the radar
display. To enter more [Ú§] marks, repeat step 2.
Up to 20 marks can be entered.
Note: If more than 20 marks are created, the oldest mark is cleared and the newly created mark is
displayed.
[II] Clearing Marks
Procedure 1 Press [MARK] key.
The [Ú§] mark will appear in the CURSOR field at the upper right of the radar display.
2 Put the cross cursor mark + on the mark to be cleared.
The [Ú§] mark will disappear. To clear another [Ú§] mark, repeat step 2.
To clear all [Ú§] marks, press [MARK] key and then hold down [CLR] key.
* Software button Õ± located at the top right corner of the radar display described in Section 2.3.3 changes
the cursor mode. When "Ú§" appears, the cross cursor is available to create "Ú§" mark.
