7.2 NAVIGATOR SETTING
This section describes the electrical adjustment procedures to be performed by service engineers during system
installation.
Make an appropriate setting for each type of equipment when inputting true bearing signals, true bearing data,
and speed data.
Settings and parameters are different for each type of equipment.
Make settings for the type of equipment to be connected.
[I] Inputting analog true bearing signals from a gyro system through
synchronization and steps
By following the procedure described in the INSTALLATION MANUAL, connect the optional NSK unit
(NCT-4106A) to this equipment. Then, follow the steps below to make settings.
In Section 7.2.1 “Ship Heading Equipment Setting (Heading Equipment),” select 1: GYRO (NCT-4106A,
JLR10, JRL20/30).
By referring to Section 7.2.2 “NSK Unit Setting,” make a setting for the gyro system.
By referring to Section 7.2.3 “True Bearing Value Setting (Set GYRO),” make a setting such that the gyro
azimuth and the radar azimuth are the same.
Refer to an applicable page for details.
CAUTION
Do not carry out the adjustments of the equipment
except authorized service persons. If wrong setting is
carried out, this may cause unstable operation.
Do not carry out the adjustments during navigation.
Otherwise, the radar performance may be affected,
resulting in an accident or trouble.
To Next Page
