7.2.5 Ship Speed Equipment Setting (Speed Equipment)
Procedure 1 Press [RADAR MENU] key twice.
The Main Menu will appear.
2 Press [7] key.
The NAV Equipment Setting Menu will appear.
3 Press [3] key.
4 Select a ship speed sensor from the
pull-down menu.
Types of selectable speed sensors:
1: Manual
2: Log
3: 2-axis log (NMEA signal: Speed over water)
4: 2-axis log (NMEA signal: Speed over ground)
5: GPS
<The alternative procedure for steps above>
1 Hold down [RADAR MENU] key.
The Code Input Menu will appear.
2 Press [0] key.
3 Move the cursor onto the “ENT” button in the Code Input menu, and
press [ENT] key.
The Adjust Menu will appear.
4 Press [6] key.
NAV Equipment Setting menu opens.
5 Perform steps 3 and 4 in the “Procedure” above.
Exit 1 Press [RADAR MENU] key.
The menu will be closed.
z The manually entered speed is effective only when
“Manual” is set.
z 2-axis log cannot be effective when the sentence
VBW of NMEA0183 is not entered.
Attention
To Next Page
