11.13 OUTPUT ENABLE SIGNAL
11ņ22
yyy
yyyy
yyyy
11
11.21 OUTPUT ENABLE SIGNAL
(1) Slave video Radar video: TIY, VD, BP(2048p), BZ (Option)
(2) Navigation information IEC61162-1/2
Radar system data: RSD
Own ship data: OSD
Tracking target data: TTM, TLL, TTD, TLB
Alarm: ALR
Auto pilot: APB
Bearing of destination: BOD
Latitude/Longitude data : GGA, GLL, RMC
Waypoint data : RMB, BWC
COG/SOG data : VTG
Cross track error: XTE
Heading data: HDT, THS
(3) Failure of RADAR J5 (NSK/COMPASS connector) նALM+, շALM-
or External alarm NCT-4106A(TB40) option
Refer to 3.21 and 3.22 in Installation manual.
(4) External monitor Multi scan monitor, Analog RGB, HD15pin Connector (Option)
11.22 STANDARD CONFIGURATION
(1) Scanner 1
(2) Display unit 1 (Processor unit, LCD unit, Keyboard unit)
(3) Power cable CFQ-5436-5 (5m)
(4) Equipment reserve parts 1
(5) Instruction manual 1 (Japanese or English)
Note: An equipment cable is optional.
Purchase an equipment cable of desired length.
