ņ17
11.16 AIS UNIT (NQA-2155)
Radar mode, synthesis mode
1) Activation 30 target
MANUAL/AUTO (by automatic activation/activation zone)
2) Display 130 target (sleeping target and activated target)
AIS data: 1 at the same time. (simple display)
Vector display: True/Relative
Past position
The message can be displayed. (broadcast message, addressed message)
Target information in numerical values: Select one of the following four
screens:
࣭Navigation information screen
True bearing, Distance, Course, Speed, CPA, TCPA,
Heading bearing, Turning speed
࣭Destination and position information screen
Destination, Estimated time of arrival, Latitude and longitude,
Position fixing equipment, RAIM, Position fixing accuracy
࣭Ship information screen
Ship name, Call sign, MMSI, IMO number, Navigation status
࣭AtoN information screen
AtoN class, AtoN type
3) Alarm Automatic activation/activation zone
Danger ship: CPA limit 0.1 to 9.9 nm, TCPA limit 1 to 99 min
Synthesis mode
4) Another ship track 20 targets. 1500 point per one target can be displayed. (including TTs)
Display color: 7 colors
(The display color of each target can be set.)
(The display color of all targets can be set by the batch. In this case, the
display color is one color.)
Interval of save: 3/5/10/30 sec, 1/3/5/10/130/160 min, 1/3/5/10 nm
Possible to storage in memory card (Option).
