7.5 MAINTENANCE MENU
ņ54
7
yyy
yyyy
7.5.3 Save of Internal Memory Data (Card2)
The system can save internal memory data such as item settings in menus onto a flash memory card. If the radar
processing circuit in the system has been replaced, the set values before the circuit replacement can be restored
by reading the set values you saved before the replacement.
To save the internal memory data onto a flash memory card (option), the card must be inserted in card slot
beforehand.
The data which are saved : Setting in menus, Trails of own ship (7000 points), Track of other ship (20 target x
1500 points, TT option), user map (256 points), etc.
The data which always changes (for example Radar echo, etc) are not saved.
[I] Copying of Internal Settings onto Card (Internal to Card)
Save the internal memory data, such as item settings in menus, onto a flash memory card.
The internal memory data should be saved at completion of system setting, and the operation condition should
be saved periodically.
Procedure 1 Insert a flash memory card into the
CARD slot 2.
The lower slot is slot 1; the upper slot is slot 2.
2 Hold down [RADAR MENU] key.
The Code Input Menu will appear.
3 Press [0] key.
4 Move the cursor onto the “ENT” button
in the Code Input menu, and press
[ENT] key.
The Adjust Menu will appear.
5 Press [2] key.
The Maintenance Menu will appear.
6 Press [4] key.
The execution check window will open to check whether or not you want to copy the
internal settings to Card2.
1 YES: Execution of copy
2 NO: Cancellation
If YES is selected, the internal memory data is saved on the flash memory card.
Exit 1 Press [RADAR MENU] key.
The Main Menu will reappear.
