3ņ105
[4] Trails Reduction
x Make a setting for thinning radar trails.
x The effect of thinning increases in order of LEVEL1 o LEVEL2 o LEVEL3 .
x Radar videos do not become obscure because of the thinning of radar trails.
OFF : Disables the Trails Reduction function.
LEVEL1 : Enables the Trails Reduction function. (Effect: Low)
LEVEL2 : Enables the Trails Reduction function. (Effect: Modest)
LEVEL3 : Enables the Trails Reduction function. (Effect: High)
[5] Time/Cont Combine
x This function superimpose-displays time radar trails and continuous radar trails.
x Operators can distinguish time radar trails from continuous radar trails by setting different colors for
both types of trails.
OFF : Disables the Time/Cont Combine function.
ON : Enables the Time/Cont Combine function.
[6] Trails Process
x Determine whether to use the video process with radar signals for plotting radar trails.
x When Trails Process is ON , radar trails are never plotted with unwanted waves, but the radar trails
of fast moving targets may not be plotted.
x When Trails Process is OFF , radar trails may be plotted with unwanted waves, but the radar trails of
fast moving targets are always plotted.
OFF : Disables the Trails Process function.
ON : Enables the Trails Process function.
[7] MAX Interval
x Select the maximum time for displaying radar trails.
x Select Short when short radar trails are often used in bays and the likes.
x Select Super Long when long radar trails are necessary for ocean navigation.
x Medium is for specification between Short and Long .
x Continuous trails are available with all the options.
Short : Sets 15 minutes as the maximum time for radar trails display.
Medium : Sets 30 minutes as the maximum time for radar trails display.
Long : Sets 60 minutes as the maximum time for radar trails display.
Super Long : Sets 12 hours as the maximum time for radar trails display.
[9] NEXT
x The file menu will appear.
