3.9 APPLIED OPERATIONS
3ņ122
3
y
y y
[5] Band Select
x Select band of antenna. This item is effective only when the antenna in connection supports two
frequencies.
X-Band : Selects the X-band side from the two frequencies.
S-Band : Selects the S-band side from the two frequencies.
X/S-band : Supports the two frequencies.
Note: This function is not functioning now. The function is for future use.
[6] Inter Switch Setting
x The master and slave antennas are switched by the simplified interswitch function.
master : Images are displayed with the antenna connected to the display unit.
The antenna connected can be controlled.
slave : The signal of the antenna connected to another display unit is obtained via the
display unit and used to display the image.
The antenna connected to another display unit cannot be controlled.
Note: The simplified interswitch cannot control the antenna of another display unit.
Only the master antenna can be controlled.
[7] Pulse Length Pattern
x Up to 3 pulses can be selected as a pulse width in a range. Select a pulse width in combination of the
three pulses.
(Example) With a 3 NM range:
Select a combination of pulses as a desired pulse width from the following three patterns:
SP1/MP1/MP2
SP1/MP1/LP1
MP1/MP2/LP1
