4ņ5

Cape

EBL2

90.0°

180

90270

VRM2

6.00NM

Bearing and range between points

A and B in this figure:

True bearing 90.0 r

Range 6.00 NM

&DSH

Own ship䇻s position

Figure 4.3

It is also possible to use EBL1 instead of EBL2 in measuring the bearing and range

between two optional points.

In this case, read EBL2 as EBL1 and VRM2 as VRM1 in the procedure above, point the

cursor to C of EBL2 in step 2, and then press [ENT] key.
