JRC JMA-5208HS User Manual

08) Description of accessories and components, including software:
System Components
JMA
-5204
JMA
-5209
JMA
-5212-4
JMA
-5212-4HS
JMA
-5212-6
JMA
-5212-6HS
JMA
-5222-7
JMA
-5222-9
Display Unit
NCD-4380
note 1
X
X
X
X
X
X
X
X
4kW Radome Scanner Unit
NKE-2043
X
6kW Slot Antenna Scanner Unit
NKE-2063A
X
10kW Slot Antenna Scanner Unit
NKE-2103-4
X
10kW Slot Antenna Scanner Unit/
High speed craft
NKE-2103-4HS
X
10kW Slot Antenna Scanner Unit
NKE-2103-6
X
10kW Slot Antenna Scanner Unit/
High speed craft
NKE-2103-6HS
X
25kW Slot Antenna Scanner Unit
NKE-2254-7
X
25kW Slot Antenna Scanner Unit
NKE-2254-9
X
Software version:
Scanner Unit NKE-2043 V03.00
Scanner Unit NKE-2063A V03.00
Scanner Unit NKE-2103-4/4HS/6/6HS V01.00
Scanner Unit NKE-2254-7/9 V01.00
Radar Processor NDC-1460 V02.00 or V02.01
NOTES:
1 The NCD-4380 consists of the NWZ-164 15” LCD Display Unit, NDC-1460 Radar Processor
Unit and NCE-7699A Operation Unit.
09) Additional Information:
Antenna length 2ft, Peak power 4kW(Magnetron) X-Band Scanner Unit: NKE-2043.
Antenna length 3.9ft, Peak power 6kW(Magnetron) X-Band Scanner Unit: NKE-2063A.
Antenna length 4ft, Peak power 10kW(Magnetron) X-Band Scanner Unit: NKE-2103-4.
Antenna length 4ft, Peak power 10kW(Magnetron) X-Band Scanner Unit: NKE-2103-4HS.
Antenna length 6ft, Peak power 10kW(Magnetron) X-Band Scanner Unit: NKE-2103-6.
Antenna length 6ft, Peak power 10kW(Magnetron) X-Band Scanner Unit: NKE-2103-6HS.
Antenna length 7ft, Peak power 25kW(Magnetron) X-Band Scanner Unit: NKE-2254-7.
Antenna length 9ft, Peak power 25kW(Magnetron) X-Band Scanner Unit: NKE-2254-9.
Signed for and on behalf of: Japan Radio Co., Ltd., Tokyo, Japan.
Place and date of issue:
Nagano-shi, Nagano, Japan Dated 27
th
June 2019
Navigation Group
Quality Assurance Department
Marine Systems
Name/function: Hiroshi Isohata / Manager
Signed: ……………….……………..

JRC JMA-5208HS Specifications

General

Brand	JRC
Model	JMA-5208HS
Category	Marine Radar
Language	English
