3.4 General Radar Operation
y
y y
3.4.19 Set Drift Correction (Set / Drift Setting)
The direction and speed of the drift are set.
This function can be used only when MAN or LOG is selected for ship-speed data.
Procedures 1 Press the [RADAR MENU] key twice.
2 Open the Set / Drift Setting menu by performing the following menu
operation.
3
4. NAV Equipment Setting
→ 3. Set/Drift Setting
3 Press the [1] key.
The Correction function can be turned on / off.
Off : Drift correction is not conducted.
On : Drift correction is conducted.
4 Press the [2] key.
The direction set numeric value input menu will appear.
5 Enter the value of the drift direction (true bearing).
For how to input numeric data on the numeric value input menu, see Section 3.3.4.
6 Press the [3] key.
The drift speed numeric value input menu will appear.
7 Enter the value of the drift speed.
For how to input numeric data on the numeric value input menu, see Section 3.3.4.
3-38
