3.4 General Radar Operation
y
y y
[â…¢] baud rate setting(Baud Rate(BPS))
This setting is enabled when beacon frequency mode is set to manual.
Procedures 1. Press the [RADAR MENU] key twice, and then perform the following
menu open procedure to open the Baud Rate menu.
4. NAV equipment Setting
→ 4. GPS Setting
3
→ 2. DGPS Setting
→ 3. Baud Rate(BPS)
2. Select the baud rate.
Following baud rate is selectable
50 bps/100 bps/200 bps
3. Press the [5] key to send the setting value to DGPS receiver.
[â…£] DGPS Mode setting(DGPS Mode)
When DGPS mode set to on, DGPS use the information from beacon to get reliable
position.
When DGPS mode set to off, the accuracy of position is same as GPS.
Procedures 1. Press the [RADAR MENU] key twice, and then perform the following
menu open procedure to open the DGPS Mode menu.
4. NAV equipment Setting
→ 4. GPS Setting
→ 2. DGPS Setting
2. Press [4] key to select the DGPS Mode.
On : DGPS use the information from beacon
Off : DGPS don’t use the information from beacon
3. Press the [5] key to send the setting value to DGPS receiver.
3.4.22 SBAS Receiver Setting (SBAS Setting)
Set to a JRC’s SBAS receiver.
SBAS receiver use the information from satellite same as that of beacon which DGPS use. So the
accuracy of position is higher than GPS.
This setting is enabled when a JRC’s DGPS is connected to the GPS connector of processor unit.
[I] SBAS mode setting (Mode)
Select the satellite or the beacon whose differential information is used.
3-44
