11.20 EQUIPMENT DISTANCE BETWEEN
OTHER INSTRUMENTS
Maximum Standard
(1) LCD Monitor to Radar Process Unit 5 m 5 m
(2) Operation Unit to Radar Process Unit 5 m 5 m
(3) Display Unit to Scanner Unit
(JMA-5312-6/6HS, JMA-5322-7/9/6HS) 65 m 20 m
(4) Display Unit to Junction box (JMA-5332-12) 30 m
*1
10 m
(5) Junction box to Scanner Unit (JMA-5332-12) 50 m
*1
20 m
*1 Total distance between Display Unit and Scanner Unit must be 65 m or less.
11.21 OTHERS (OPTION)
• Coast line ROM card
• Memory card
• Interswitch unit (NQE-3141)
• Rectifier unit (NBA-5111)
• Power Control Unit (NQE-3167)
11-19
