11.14 OPERATION UNIT NCE-5171
(1) Structure Structure of operation unit is separate from
processor unit.
Desk-Top type
Correspond Flush mount
(2) Switch
GAIN/PL : Adjust the reception gain. (Transmit pulse width
can be changed by PUSH-SW.)
AUTO-SEA : Sea clutter suppression.
(AUTO/MANU can be changed by PUSH-SW.)
AUTO-RAIN : Rain clutter suppression.
(AUTO/MANU can be changed by PUSH-SW.)
MULTI : Change the setting. (Adjustment item can be
changed by PUSH-SW)
EBL (Electric Bearing Line) : Rotate the bearing of the EBL (Floating EBL
ON/OFF can be changed by PUSH-SW.)
VRM (Variable Range Marker) : Change the VRM range.
(3) Operation switch
Trackball : Move the cursor mark.
STBY/OFF (Standby/Power off) : Stop transmit, Power off.
TX/OFF (Transmit Start/Power Off) : Start transmit, Power off
PANEL (Brightness of Keyboard Adjustment) : Brightness of keyboard switch adjust.
ALARM ACK (Alarm Acknowledge) : Acknowledge and stop alarm.
EBL1 : Selection display and non-display of EBL1.
EBL2 : Selection display and non-display of EBL2.
VRM1 : Selection display and non-display of VRM1.
VRM2 : Selection display and non-display of VRM2.
RANGE+ (Increase Display Range) : Increase display range.
RANGE- (Decrease Display Range) : Decrease display range.
ACQ (Acquisition) : Target acquisition
TGT DATA (Numeric Display) : Numeric display of tracking target.
TGT CNCL (Cancel of Selection) : Release of selection of tracking target.
MOB (Marker) : Turning on and release marker.
ENT (Enter) : Left side button of trackball.
CLR/INFO (Clear/Information) : Right side of trackball.
MAP (Display Mode) : Selection display and non-display of MAP(NAV
LINE, etc…).
Selection of Rader, Synthesis and Plotter mode.
AZI MODE (Display Azimuth Mode) : Selection of North-up, Course-Up, Head-Up.
TM/RM (True/Relative Motion) : Selection true motion, relative motion.
RR/HL (Range Ring/Heading line) : Selection display and non-display of fixed ring
and heading line.
OFF CENT(Off Center) : Off center operation
AZ (Automatic Acquisition/Activate zone) : Setting and release of acquisition/activation zone.
VECT T/R (True/Relative Motion Vector) : Selection of true motion and relative motion of
vector.
TRAILS : Switching trails display time.
DAY/NIGHT : Selection of screen arrangement of color.
FUNC (Function) : Selection of signal processing.
USER KEY1 : User assignment key1.
USER KEY2 : User assignment key2.
RADAR MENU : Rader menu.
MARK : Selection display and non-display of mark.
TT MENU : Target tracking menu.
11-15
