11.18 AVAILABLE OUTPUT SIGNAL
(1) Slave video Radar video : TIY, VD, BP (2048 p), BZ (Terminal board TB4302)
(2) Navigation information Send capability Port : .NAV1, NAV2, GPS port at terminal board TB4303.
NMEA Connecter at rear of the process unit (D-Sub 9 PIN). IEC61162-1/2
Radar system data : RSD
Own ship data : OSD
Tracking target data : TTM, TLL, TTD, TLB, JRC-ARPA
AIS target data : TTM, TLL, TTD, TLB
Alarm : ALR
Auto pilot : APB
Bearing of destination : BOD
Latitude/Longitude data : GGA, GLL, RMC
Waypoint data : RMB, BWC
COG/SOG data : VTG
Cross track error : XTE
Heading data : HDT, THS
(3) External alarm Default setting : normally closed contact
Maximum current : 200 mA
(SYSALM, ARPAALM port at terminal board TB4303).
(4) External monitor Multi scan monitor, Analog RGB, HD15 pin Connector
11.19 STANDARD CONFIGURATION
(1) Scanner Unit 1
(2) Display Unit 1 (Process unit, LCD unit, Operation unit)
(3) Equipment cable JMA-5312-6/6HS, JMA-5322-7/9/6HS
Standard : 20 m
JMA-5332-12
Display unit to junction box Standard : 10 m
Junction box to scanner Standard : 20 m
(4) Equipment reserve parts 1
(5) Instruction manual 1 (Japanese or English)
