3.4 General Radar Operation
y
y y
3.4.24 Set Radar Alarm (RADAR Alarm)
The radar alarm can be issued when targets have entered the radar alarm range.
Turning on / off the radar alarm (Sector RADAR Alarm)
Procedures 1 Press the [AZ] key for 2 seconds.
3
The AZ Menu will appear.
2 Open the Sector RADAR Alarm menu by performing the following
menu operation.
4. RADAR Alarm
→ 1. Sector RADAR Alarm
3 Press the [1] key or [2] key.
Sector Alarm1 or Sector Alarm2 is turned on / off.
On : The radar alarm is turned on.
Off : The radar alarm is turned off.
Change the Radar Alarm Setting (RADAR Alarm Mode)
Procedures 1 Press the [AZ] key for 2 seconds.
The AZ Menu will appear.
2 Open the Sector RADAR Alarm menu by performing the following
menu operation.
4. RADAR Alarm
3 Press the [5] key.
Sector Alarm1 or Sector Alarm2 is turned in / out.
In : When a target has entered the zone, RADAR Alarm (In) is issued.
Out : When a target has departed the zone, RADAR Alarm (Out) is issued.
4 Press the [6] key.
Selected items for Sensitivity Level will be displayed.
5 Press numeric keys corresponding to the Sensitivity Level.
The threshold video level increases in order of
Level1 → Level2 → Level3 → Level4 .
3-48
