3.12.6 Display C-MAP Card [MAP]
• Turn off the power supply to the system, insert a C-MAP card into either card slot 1 (lower) or
card slot 2 (upper), and then press the [Map] key. Coastlines will be displayed.
• Be sure to turn off the power supply to the system before inserting or removing a C-MAP card.
If a C-MAP card is inserted or removed with the power supply turned on, a malfunction will
occur on the display.
• When using a compact flash memory type C-MAP card, be sure to use a PCMCIA(PC card)
adapter for the compact flash memory card which is commonly sold at retail outlets.
• Only one C-MAP card can be inserted. If two C-MAP cards are inserted at the same time, a
malfunction will occur on the display.
• With regard to the range of the chart to be displayed, refer to the catalog.
• Do not simultaneously insert a JRC coastline ROM card and an ERC card (issued by Japan
Hydrograp ic Association) into the card slot. A malfunction will occur on the display.
h
Procedures 1 Press the [Map] key while a C-MAP card is being inserted into the
ard slot.
c
Coastlines will be displayed.
For the insertion and removal of the card, see HOW TO INSERT AND REMOVE A
CARD in the appendix.
Insert or remove a C-MAP card while the power supply to the system is turned off.
C-MAP display setting (C-MAP Setting)
Procedures 1 Press the [Map] key for 2 seconds.
The Map Setting menu will appear.
2 ress the [2] key. P
T
he C-Map Setting menu will appear.
[1] LAT/LON Line Display
• Set whether to display latitude / longitude lines on the C-MAP.
On : Latitude / longitude lines are displayed.
Off : Latitude / longitude lines are not displayed.
[2] Depth Display
• Set whether to display water depth values on the C-MAP
On : Water depth values are displayed.
Off : Water depth values are not displayed.
3-117
