7.2 Settings
yyy
yyyy
7.2.11 Transmit/Receive Data Setting (LAN Port Setting)
The system can receive data from other system via the JRC-LAN. The JRC-LAN is designed for
interoperation of JRC systems. The JRC-LAN network can synchronize data of systems connected to the
net work.
* To connect JRC-LAN, LAN cable and HUB (option) is necessary.
For details, contact the JRC offices.
Note: If the connection is not suggested from JRC offices, don't connect PC or other maker's system.
・ Connecting PC or other maker's system can cause a lower performance to radar system.
・ Connecting PC or other maker's system can cause a lower performance to them.
[I] Receive Route Data Setting (Route Type)
Set route type.
Note: ECDIS type data and Plotter type data are incompatible.
Route Type set Plotter model.
RADAR : JMA-5300/5200 series
JMA-5300MK2 series (factory default : Plotter )
Plotter : JLZ-700
CAUTION
Never change except following setting. Failure to comply
may result in accidents that would lower performance.
7
Procedures 1. Press the [RADAR Menu] key for 2 seconds.
The Code Input menu will appear.
2. Press [5] [3] [0] [0] [1] key.
3. Put the cursor on the ENT button, and press the [ENT] key.
The Utilities menu will appear.
2. Open the Plot menu by performing the following menu operation.
5. Plot
3. Press [3] key, and 3. Route Type set to ECDIS .
7-26
