7.2 SETTINGS
This section describes the electrical adjustment procedures to be performed by service engineers during
system installation.
CAUTION
Any adjustments must be made by specialized service
personnel.
Incorrect settings may result in unstable operation.
Do not make any adjustments during navigation. Failure
to comply may result in adverse effects on the radar
function which may lead to accidents or equipment failure.
7.2.1 Communication Port Setting (COM Port Setting)
External sensor signals are input to the radar equipment through a communication port. The radar
equipment has five communication ports. For signals to be input from sensors or to be output to the
sensors, communication ports need to be set in accordance with the sensors.
[I] Baud Rate Setting
Set the baud rate of the signal to be input to the COM port.
Procedures 1. Open the Serviceman Menu.
2. Open the Baud Rate menu by performing the following menu
operation.
2. Installation Menu
→ 5. COM Port Setting
→ 1. Baud Rate
7-11
