11.17 AVAILABLE INPUT SIGNAL
Receive capability Port : .NAV1, NAV2, GPS port at terminal board TB4303. NMEA Connecter at rear of
the process unit (D-Sub 9 PIN)
(1) Navigation equipment : IEC61162-1/2
Longitude/Latitude : GGA > RMC > RMA >
GNS/GLL
Waypoint : RMB>BWC>BWR
COG/SOG : RMC>RMA>VTG
SPEED : VBW
Day/Time information : ZDA
Alarm
acknowledge : ACK
Rate of Turn : ROT
Rudder : RSA
(2) Bearing signal : GYRO-SYNC : 360X, 180X, 90X, 30X. (GYRO I/F Unit)
GYRO-STEP : 360X, 180X, 90X, 30X. (GYRO I/F Unit)
JRC-NSK format (JLR-10, 20, 30) (COMPASS Connector at rear
of the process unit)
IEC61162-2 38400 bps : THS>HDT (over 40 Hz) (COMPAS port
at terminal board TB4303).
IEC61162-1 4800 bps : HDT>HDG>HDM>VHW (COMPAS port
at terminal board TB4303). Can’t be use for target tracking.
(3) Speed signal : LOG-SYNC : 360X, 180X, 90X, 30X. (GYRO I/F Unit)
LOG-PULSE : 800, 400, 200, 100. (GYRO I/F Unit)
(4) External event mark : Contact input (EVENT port at terminal board TB4303).
(5) Radar buoy : Negative input (RBVD port at terminal board TB4302).
(6) Depth : DPT>DBS>DBT>DBK, JRC format
(7) Water temperature : MTW, JRC format
(8) Tendency : CUR, JRC format
(9) Direction of wind, velocity of wind : MWV, MWD
(10) AIS : VDM, VDO
Note : The Speed measuring accuracy of speed sensor shall confirm to IMO Resolution MSC.96(72).
The measuring accuracy of GPS shall confirm to IMO Resolution MSC.112(73).
