7.4.5 Update of Character String Data (String Data Update)
The system is designed to transfer and display external character strings as the second language display.
The second language is factory-set to "Japanese."
Ask our agent or sales department for the supply of character strings to be updated.
To update character strings, the flash memory card (option) containing the character string file must be
inserted in card slot 2.
Procedures 1. Open the Serviceman Menu.
2. Open the String Data Update menu by performing the following menu
operation.
3. Maintenance Menu
→ 6. String Data Update
3. Select Yes in the Confirmation Window.
The character string file on the flash memory card is read into the system, and the
second language area is updated.
To display the read character strings in the second language, select Other in the
menu shown in Section 7.2.6.
7-43
